SLW01-125KHz LF proximity RFID wristband is developed based on SMARTCHIP SMC4100 IC, which is connected to a coil and then embedded into silicon wrist band. It is the same with SLW01-13.56MHz HF MIFARE wristband, while the latter is developed based on NXP MF1 IC S50.
| SLW01-125K | ||
| Frequency | 125KHz | |
| Chipset Inbuilt | TK4100(SMC4100) | |
| Protocol | ISO10536 | |
| Unique ID | 40(bit) | |
| Supported Readers | SL102 | |
| SLW01-13.56M | ||
| Frequency | 13.56MHz | |
| Chipset Inbuilt | MIFARE 1K(NXP, MF1 S50) | |
| Protocol | ISO14443A | |
| Unique ID | 32(bit) | |
| EEPROM Size | 1024(Byte) | |
| Data Retention | 10(year) | |
| Write Endurance |
100,000(cycles) | |
| Supported Readers | SL500L, SL500A, SL500F, SL013, SL018, SL025B, SL025M, SL030, SL031, SL032, SL040, SL040A, SL060, SL600 |
|
| Material | Silicon | |
| Temperature | -10°C ~ +50°C | |
| Dimension | 65mm | |
| Quantity | Unit Price (USD) | |
| 125KHz | 13.56MHz | |
| 1 - 99 | $1.90 | $2.30 |
| 100 - 999 | $1.70 | $2.10 |
| 1,000 - 4,999 | $1.50 | $1.90 |
| 5,000 - 9,999 | $1.40 | $1.70 |
| > 10,000 | $1.28 | $1.50 |
